SLIDE 16: PERFORMANCE METRICS & BENCHMARK RESULTS
Presenter: Rida - 40 seconds
Graph 1: Cryptographic Operation Latency
- Bar chart: Encryption vs Decryption vs Sign vs Verify
- All operations: less than 2ms on Pi 5
- Y-axis: milliseconds (0-2.5)
Graph 2: Key Deletion Latency
- Line graph: Time vs Number of keys (1, 5, 10, 50 keys)
- All deletions: less than 100ms
- Demonstrates O(n) linear scaling
Graph 3: Tamper Detection End-to-End Latency
- Wire break → ESP32 detects → UART message → Pi receives → HSM locked
- Total latency: less than 200ms
- Breakdown: Detection (10 microseconds) + UART (50ms) + Processing (100ms) + API response (40ms)
Graph 4: System Resource Usage During Operations
- CPU usage: less than 5% idle, less than 20% during crypto
- Memory: ~150MB baseline, +50MB during operation
- Network: less than 1 Mbps on direct ethernet
Graphics: Professional charts with labels and legends
