Create a clean, publication-quality schematic diagram suitable for a scientific review paper. The diagram should present a hierarchical taxonomy titled “Folding Wingtip Concepts” at the top center.
Structure:
Three main branches arranged horizontally beneath the title:
Actuation
Folding Architecture
Application Domain
Under Actuation, include three subcategories:
Passive
Semi-active
Active
Under Folding Architecture, include:
Discrete
Hinge-less
Under Application Domain, include:
Load alleviation & aeroelasticity
Flight performance & operations
Flight mechanics & control
Design requirements:
Use a minimal, professional style (no gradients or shadows)
White background, black or dark gray text
Thin, consistent connector lines between nodes
Rectangular boxes with subtle rounded corners
Use a serif or clean sans-serif font typical of journal figures (e.g., Times New Roman, Helvetica)
Ensure even spacing, alignment, and symmetry
Maintain high resolution (vector-style or 300 dpi equivalent)
Avoid decorative elements; prioritize clarity and readability
