Highly detailed professional technical exploded isometric cutaway view of a PEM electrolyzer cell for Projekt Nomad, clean engineering illustration style, white background, precise part separation with leader lines and labels, ultra high technical accuracy,
Central cross-section showing:
- Titanium bipolar plates with flow channels
- IrO₂ anode catalyst layer (oxygen side)
- Nafion PEM membrane (thin glowing purple layer)
- Platinum cathode catalyst layer (hydrogen side)
- H+ proton migration through membrane
- Oxygen bubbles at anode (red)
- Hydrogen bubbles at cathode (blue)
- Water input, H2 & O2 output channels
Realistic materials, gas bubble formation, current flow, temperature gradient, professional hydrogen electrolysis engineering diagram, cinematic technical visualization, masterpiece, 8k, sharp focus
