The unit is designed with a "Deep-Profile" configuration to maximize internal storage volume while maintaining a slim frontal footprint.
Height: 330 mm (33 cm)
Width: 200 mm (20 cm)
Depth: 380 mm (38 cm)
Aesthetic Style: Modern Industrial with exposed bolted edges for a rugged, high-security appearance.
2. Panel Layout & Cutting List (Fiber Laser Cutting)
The chassis consists of six primary panels. All cuts, including component apertures, must be performed via precision CNC Fiber Laser.
Panel Dimensions (mm) Description & Component Integration
Front Panel (Door) 330 × 200 Interactive interface (Apertures for: LCD, NV200, QR, LED Button, Speaker).
Rear Panel 330 × 200 Features laser-cut cooling louvers and power cable entry port.
Side Panels (x2) 330 × 380 Long rectangular panels defining the unit's depth.
Top Panel 200 × 380 Upper enclosure lid.
Bottom Panel 200 × 380 Base plate with 4x pre-drilled holes for floor/surface mounting (Bolt-down).
3. Material Specifications & Durability
To ensure maximum security and a premium "heavy-duty" feel:
Material Type: Cold Rolled Carbon Steel.
Door Thickness: 8 mm (Reinforced to prevent drilling and prying).
Chassis Thickness: 4 mm for all other sides.
Finish: Industrial Powder Coating in Anthracite Dark Grey with a textured finish, or a Dark Brushed Steel effect.
4. Front Panel Interface Layout
Components are to be arranged vertically and ergonomically as follows:
Upper Section: Centered aperture for a 3.5-inch LCD screen (rear-mounted).
Middle Left: Vertical slot for the NV200 Spectral Banknote Validator.
Middle Right: 16mm circular cutout for the Stainless Steel LED Push Button.
Below Button: 70 × 30 mm rectangular laser-cut grill for the Internal Speaker.
Lower Section: Square aperture for the 2D QR Barcode Scanner.
5. Assembly Dynamics & Mechanical Features
Internal Frame: Internal 5 mm L-Bracket reinforcement angles welded at the corners for structural integrity.
External Fastening: Side, top, and bottom panels are joined using Security Torx Bolts with exposed stainless steel heads to emphasize the industrial look.
Hinge System: Heavy-duty hidden internal hinges allowing a minimum 110° door opening angle.
Locking Mechanism: An electronic Solenoid or Motorized Bolt system integrated with the main controller board for automated access.
6. Technical Manufacturer Notes
Anti-Pry Flange: The door frame must include an "anti-pry" lip or flange to prevent the insertion of crowbars or flat-head tools.
Serviceability: Ensure the NV200 Cash Box is easily accessible and removable once the main door is opened.
Electronics Mounting: Provide internal threaded bosses (standoffs) on the rear or side interior to mount PCBs (e.g., Arduino, Raspberry Pi, or custom Controller Boards).
Thermal Management: Ensure the rear louvers provide sufficient airflow for the validator and power supply units.
