Highly detailed technical exploded isometric view of the full Nomad H2 energy cycle, professional marine renewable engineering illustration, white background,
Closed loop:
- Solar + Wind → PEM Electrolyzer → H2 storage (metal hydride)
- H2 → Fuel cell or burner → Electricity + Heat + Water
- O2 → Aquaponics
- Waste heat → Stirling/ORC
- Recycled water back to electrolyzer
Realistic ship deck integration, clear flow arrows in cyan/blue/green, professional autonomous vessel hydrogen system diagram, ultra detailed, cinematic technical masterpiece, 8k
