Create a clean, professional 2-panel educational infographic titled "MOPA Laser Parameters: Time vs. Space". Panel 1 (Left side - Time Domain): Show a MOPA laser source labeled "60W MOPA Source". From it, draw a horizontal timeline representing 1 second. On this timeline, place two distinct magnified callout boxes: Frequency (kHz): Show a dense cluster of sharp pulses (e.g., 200 kHz) vs. a sparse cluster (e.g., 20 kHz). Label it: "Frequency = Number of pulses per second." Q-Pulse (ns): Zoom in on a single pulse. Draw two versions: a very short, tall spike labeled "2 ns (Short = High Peak Power)" and a wider, shorter plateau labeled "200 ns (Long = Low Peak Power)". Label it: "Q-Pulse = Duration of one touch." Panel 2 (Right side - Spatial Domain): Show a galvanometer scan head (labeled "Galvo Head") moving a laser beam across a flat metal sheet. Draw a zigzag scan path (hatch lines). Speed (mm/s): Add a speedometer icon next to the galvo head. Draw arrows showing fast vs. slow movement. Label it: "Speed = Mirror movement speed." Result on Material: Along the scan path, draw two distinct rows of overlapping dots/craters. Row A (Low Frequency): Widely spaced, deep craters. Row B (High Frequency + Short Q-Pulse): Closely spaced, shallow, clean spots. At the bottom, add a formula box: "Peak Power = Power (W) / (Freq (kHz) × Q-Pulse (ns))". Use a technical, blueprint-style color scheme (dark background with neon green/yellow laser lines and white text).
