SLIDE 16: PERFORMANCE METRICS & BENCHMARK RESULTS Presenter: Rida - 40 seconds Graph 1: Cryptographic Operation Latency - Bar chart: Encryption vs Decryption vs Sign vs Verify - All operations: less than 2ms on Pi 5 - Y-axis: milliseconds (0-2.5) Graph 2: Key Deletion Latency - Line graph: Time vs Number of keys (1, 5, 10, 50 keys) - All deletions: less than 100ms - Demonstrates O(n) linear scaling Graph 3: Tamper Detection End-to-End Latency - Wire break → ESP32 detects → UART message → Pi receives → HSM locked - Total latency: less than 200ms - Breakdown: Detection (10 microseconds) + UART (50ms) + Processing (100ms) + API response (40ms) Graph 4: System Resource Usage During Operations - CPU usage: less than 5% idle, less than 20% during crypto - Memory: ~150MB baseline, +50MB during operation - Network: less than 1 Mbps on direct ethernet Graphics: Professional charts with labels and legends
